Molybdenum is a refractory metal with a high melting point and low thermal expansion, used as a key material across the semiconductor, display, glass and energy industries.
Molybdenum is a refractory metal with a high melting point and low thermal expansion, used as a key material across the semiconductor, display, glass and energy industries.
Molybdenum is a refractory metal with a high melting point and low thermal expansion, used as a key material across the semiconductor, display, glass and energy industries.
Molybdenum
Not many metals hold up at high temperature, and fewer still can be worked into thin sheet and wire. Molybdenum is in that rare position.
Molybdenum
Not many metals hold up at high temperature, and fewer still can be worked into thin sheet and wire. Molybdenum is in that rare position.
Why the geometry survives at high temperature
Heating elements that go through repeated heating and cooling cycles do not sag. Form tolerances hold, so the temperature distribution holds with them.
Its expansion coefficient is close to that of AlN and alumina, so interfacial stress stays low in embedded structures. This is the main reason molybdenum is used as the heating element in AlN heaters.
At 10.2 g/cm³ it is about 53% of tungsten. For the same geometry the weight is halved, which helps in large heat-shield structures and moving parts.
Key Properties
The dimensions listed are the range we can supply. Final feasibility depends on the combination of grade, quantity and tolerance and on the material condition you request, so send us a drawing and we will confirm and reply.
Why the geometry survives at high temperature
Heating elements that go through repeated heating and cooling cycles do not sag. Form tolerances hold, so the temperature distribution holds with them.
Its expansion coefficient is close to that of AlN and alumina, so interfacial stress stays low in embedded structures. This is the main reason molybdenum is used as the heating element in AlN heaters.
At 10.2 g/cm³ it is about 53% of tungsten. For the same geometry the weight is halved, which helps in large heat-shield structures and moving parts.
Key Properties
The dimensions listed are the range we can supply. Final feasibility depends on the combination of grade, quantity and tolerance and on the material condition you request, so send us a drawing and we will confirm and reply.
Why the geometry survives at high temperature
Heating elements that go through repeated heating and cooling cycles do not sag. Form tolerances hold, so the temperature distribution holds with them.
Its expansion coefficient is close to that of AlN and alumina, so interfacial stress stays low in embedded structures. This is the main reason molybdenum is used as the heating element in AlN heaters.
At 10.2 g/cm³ it is about 53% of tungsten. For the same geometry the weight is halved, which helps in large heat-shield structures and moving parts.
Key Properties
The dimensions listed are the range we can supply. Final feasibility depends on the combination of grade, quantity and tolerance and on the material condition you request, so send us a drawing and we will confirm and reply.
Comparison
Refractory metals compared
Properties
Iron
Iron
Nickel
Nickel
Molybdenum
Molybdenum
Melting point (°C)
Melting point (°C)
1,538
1,538
1,455
1,455
2,623 (very high)
2,623 (very high)
Thermal conductivity (W/m·K)
Thermal conductivity (W/m·K)
80
80
91
91
138 (excellent)
138 (excellent)
Thermal expansion (µm/m·K)
Thermal expansion (µm/m·K)
11.8
11.8
13.4
13.4
4.8 (very low)
4.8 (very low)
Key features
Key features
The most common structural metal
The most common structural metal
A general-purpose alloy with excellent corrosion resistance
A general-purpose alloy with excellent corrosion resistance
The standard material for high-temperature precision work
The standard material for high-temperature precision work
Supply Forms
Applications
Supply Forms
Applications
